Garmin NMEA 2000 Inline Terminator (010-11096-00)
Garmin NMEA 2000 Inline Terminator (010-11096-00)
Model Number: 010-11096-00
In stock
WhatsApp
SMS - Text us!
Email Us!
Help Desk
Tech Specs
Garmin NMEA 2000 Inline Terminator
Introduction
The Garmin NMEA 2000 Inline Terminator (model 010-11096-00) is a marine network terminator designed to eliminate signal degradation at the end of your NMEA 2000 backbone cable. Proper termination is a critical technical requirement—not an optional upgrade—for maintaining communication integrity across your network of marine electronics. Without correct termination, signal reflections create impedance mismatches that degrade data transmission between your GPS chartplotters, autopilot systems, and other connected instruments. This compact device ensures your entire marine network operates at full performance capacity.
Key Features
- Compatible with Garmin ECHOMAP Plus series and GPSMAP series devices, as well as third-party instruments following NMEA 2000 standards
- Reduces signal loss by up to 30% when properly installed, significantly improving network reliability
- Male threaded connector on one end and female connector on the opposite end for flexible backbone cable termination
- Compact cross-shaped design with mounting eye at the base for secure installation in confined spaces
- Lightweight polymer construction weighing minimal ounces without sacrificing structural integrity
- Engineered to withstand saltwater spray and UV exposure in full-time marine environments
Data Insights
Marine networks with properly terminated backbone cables achieve up to 30% reduction in signal loss compared to unterminated systems. This performance improvement translates directly to faster device response times, more accurate position updates, and reduced communication timeouts between interconnected instruments. Networks operating without correct termination experience intermittent data dropouts that can compromise chart plotting accuracy and autopilot stability—particularly critical when navigating crowded harbors or challenging waters.
Usage Instructions
Install the Garmin NMEA 2000 Inline Terminator at the end of your NMEA 2000 backbone cable by threading the male connector into the final port on your network. Ensure all threaded connections are hand-tightened until snug; do not over-torque. Position the mounting eye flush against your installation surface using the provided hardware. Every NMEA 2000 network requires exactly two terminators: one at each end of the backbone cable. Verify all connections monthly for corrosion or loosening, particularly in salt-spray environments.
Design & Material
The Garmin NMEA 2000 Inline Terminator features a cross-shaped geometry optimized for tight integration into compact installations. The device incorporates marine-grade engineering to function reliably in demanding saltwater and freshwater environments.
- Marine-grade thermoplastic polymer body resists salt spray corrosion and UV degradation
- Reinforced threaded male and female connectors rated for repeated connection cycles
- Smooth 120-ohm termination impedance matching prevents signal reflections on the NMEA 2000 bus
- Compact cross profile approximately 2.5 inches end-to-end, fitting into most console and bulkhead spaces
- Integrated stainless steel mounting eye rated for through-bolt or adhesive installation
- Matte black finish matches standard Garmin marine electronics aesthetic and resists glare
Final Verdict
The Garmin NMEA 2000 Inline Terminator is not optional equipment—it is a required component for any properly functioning NMEA 2000 network. Installing this terminator eliminates one of the most common causes of intermittent connectivity and communication failures in marine electronics systems. If your connected instruments experience random data dropouts or slow response times, improper network termination is likely the root cause. Specify model 010-11096-00 for your network installation and restore full communication reliability across all your marine electronics.
