Garmin AIRMAR B175L 20° Tilt Transducer (010-11938-22)

Introduction

The Garmin AIRMAR B175L 20° Tilt Transducer is engineered for anglers who require outstanding deep-water sonar performance combined with a clean, low-profile installation. Designed specifically for boats with higher hull deadrise, the integrated 20° tilted element automatically compensates for hull angle, ensuring accurate sonar beam alignment while eliminating the need for a traditional fairing block.

Its premium bronze thru-hull housing extends less than one-quarter inch below the hull, minimizing drag and allowing safe use with trailer rollers and bunks. Operating within the low-frequency 40–60 kHz CHIRP range, the transducer delivers excellent bottom penetration, dependable fish detection, and detailed underwater imaging at depths of up to 2,500 feet.

Built for fiberglass and wood hulls, the Garmin AIRMAR B175L 20° Tilt is an ideal choice for offshore anglers seeking reliable sonar performance, simplified installation, and long-lasting durability.

Key Features

Powerful 1 kW CHIRP Sonar

• High-performance 1 kW CHIRP transducer.
• Excellent deep-water fish-finding capability.
• Produces clear bottom and fish returns.
• Improves underwater target separation.

Low-Frequency Performance

• Operating frequency range of 40–60 kHz.
• Optimized for offshore and deep-water fishing.
• Excellent bottom penetration at greater depths.
• Reliable sonar performance in challenging conditions.

Integrated 20° Tilted Element

• Internal 20° tilt compensates for steeper hull deadrise.
• Eliminates the need for a fairing block.
• Maintains accurate sonar beam alignment.
• Simplifies installation while maximizing sonar efficiency.

Flush-Mounted Bronze Housing

• Durable marine-grade bronze construction.
• Extends less than 1/4 inch below the hull.
• Minimizes drag through the water.
• Safe for trailer rollers and bunks.

Deep-Water Capability

• Maximum operating depth of 2,500 feet.
• Excellent bottom tracking performance.
• Reliable detection of fish and underwater structures.
• Designed for demanding offshore applications.

Broad Compatibility

• Compatible with supported Garmin sonar systems.
• Standard 8-pin connector.
• Designed for fiberglass and wood hulls.
• Suitable for recreational and professional fishing vessels.

Performance Insights

The Garmin AIRMAR B175L 20° Tilt combines powerful low-frequency CHIRP technology with an integrated 20° tilted element that maintains optimal sonar beam orientation on boats with steeper hull angles. This design improves sonar accuracy while removing the complexity and drag associated with external fairing blocks.

Operating in the 40–60 kHz frequency range, the transducer delivers excellent bottom penetration and dependable fish detection in deep offshore waters. Its streamlined bronze housing reduces turbulence while providing exceptional durability for long-term marine use.

Whether searching for game fish over deep structures or tracking bottom contours offshore, the B175L provides the reliable performance experienced anglers demand.

Usage Instructions

Install the transducer following the included Garmin and AIRMAR installation instructions. The 20° tilt model is designed specifically for fiberglass and wood hulls with higher deadrise angles, allowing proper sonar beam alignment without a fairing block.

Connect the 8-pin transducer to a compatible Garmin sonar or chartplotter system and configure sonar settings according to your fishing conditions. Keep the transducer face clean and periodically inspect the installation to maintain peak sonar performance.

Always follow the installation instructions carefully to avoid damage to the vessel or transducer.

Design & Construction

Built for demanding marine environments, the Garmin AIRMAR B175L 20° Tilt features a premium bronze flush-mounted housing that provides outstanding durability while minimizing hull protrusion. Its internally tilted transducer element delivers accurate sonar performance without external mounting hardware, creating a cleaner installation and improved hydrodynamics.

Design Highlights

• Premium 1 kW CHIRP transducer
• Flush-mounted bronze housing
• Integrated 20° tilted element
• No fairing block required
• Low-frequency operation: 40–60 kHz
• Maximum depth capability of 2,500 feet
• Less than 1/4-inch hull protrusion
• Excellent deep-water penetration
• Accurate bottom tracking
• Enhanced fish target separation
• Standard 8-pin connector
• Compatible with Garmin sonar systems
• Designed for fiberglass hulls
• Designed for wood hulls
• Trailer-friendly low-profile installation
• Rugged marine-grade construction

Final Verdict

The Garmin AIRMAR B175L 20° Tilt Transducer is an excellent choice for anglers operating boats with steeper hull deadrise who want professional-grade CHIRP sonar performance without the complexity of a fairing block. Its powerful 1 kW output, low-frequency deep-water capability, durable bronze housing, and integrated 20° tilt provide dependable fish-finding performance, precise bottom tracking, and streamlined installation for serious offshore adventures.
